Spesifikasi Aprilia Tuono R 2009
Displacement: 997.60 ccm (60.87 cubic inches)
Engine type: V2
Stroke: 4
Power: 136.78 HP (99.8 kW)) @ 9500 RPM
Torque: 107.00 Nm (10.9 kgf-m or 78.9 ft.lbs) @ 8500 RPM
Compression: 11.8:1
Bore x stroke: 97.0 x 67.5 mm (3.8 x 2.7 inches)
Fuel system: Injection. Integrated electronic engine management system. Indirect multi-point electronic fuel injection. 57 mm diameter throttle bodies. 10.3 litre airbox with Air Runner ram air intake.
Valves per cylinder: 4
Fuel control: DOHC
Ignition: Digital electronic ignition, integrated with the fuel injection system. One spark plug per cylinder.
Starter: Electric
Lubrication system: Dry sump with separate oil reservoir. Double trochoid pump with oil cooler. Steel oil reservoir.
Cooling system: Oil & air
Gearbox: 6-speed
Transmission type final drive: Chain
Clutch: Multiple disc in oil bath with patented PPC power-assisted hydraulic control. Metal braided clutch hose. Radial master cylinder.
Dry weight: 185.0 kg (407.9 pounds)
Seat height: 810 mm (31.9 inches) If adjustable, lowest setting.
Overall height: 1,100 mm (43.3 inches)
Overall length: 2,025 mm (79.7 inches)
Wheelbase: 1,410 mm (55.5 inches)
Frame type: Box section sloping twin-spar frame in aluminium alloy.
Rake (fork angle): 25.0°
Trail: 104 mm (4.1 inches)
Front suspension: Showa 43 mm upside-down fork with adjustment for spring preload, compression and rebound damping.
Front tyre dimensions: 120/70-ZR17
Front suspension travel:120 mm (4.7 inches)
Front brakes: Double disc. Bremo
Front brakes diameter: 320 mm (12.6 inches)
Rear suspension: Aluminium alloy double member swingarm. APS (Aprilia Progressive System) rising rate linkages. Öhlins Racing piggy-back monoshock with adjustment for spring preload, compression and rebound damping. Wheel travel 133 mm.
Rear tyre dimensions: 180/55-ZR17
Rear brakes: Single disc. Bremo
Rear brakes diameter: 220 mm (8.7 inches)
Exhaust system: Two silencers with three way catalytic converter and lambda probe oxygen sensor (Euro 3).
Power/weight ratio:0.7394 HP/kg
Other specifications
Fuel capacity: 18.00 litres (4.76 gallons)
Reserve fuel capacity: 4.00 litres (1.06 gallons)
Color options: White, blue, black,Red
Aprilia Tuono R White Color
